4:1 양방향 패러럴 프린터 공유기
 |
Bitronics Auto Switch |
 |
AS8144B works similarly with AF-142. It allows users 4 PCs to scan the print task needs and transfers data to the printer. AS8144B also supports 2-way operation (1 PC to multiple serial devices and provides broadcasting function. | |
 |
제품특징 |
 | |
 |
|
Bi-tronics and Centronics compatible. |
|
Reversible operation for 1-in-4-out or 4-in-1-out. |
|
Supports IEEE-1284 nibble mode. |
|
Print job management is first come, first serve. |
|
Supports broadcast mode. |
|
Selects ports by button and software code operation. |
|
Non-powered operation. |
|
HP Laser Jet, Canon, Epson and NEC Compatible. |
|
OS Compatibility: WIN98?WIN ME?WIN 2K and WIN XP. | |
| |
| |
제품구성 |
| |
|
|
1x Auto Switch |
|
1x User Manual |
|
1x 3.5" Disk | |
| |
|
다이어그램 |
| |
|
|
|
제품사양 |
| |
|
| Connectors |
5 x DB-25 Female |
| LEDs |
Printer Activity |
4 |
| Port Selection |
Input |
(4 > 1) Auto / Manual PC Selection |
| Output |
(1 > 4) Software / Manual Printer Selection |
| Input Arbitration |
First Come First Served (4 > 1) |
| Broadcast |
Yes (1 > 4) |
| Timeout Selection |
15, 45 Seconds (4 > 1) |
| Power Consumption |
DC 9V, 0.45W (Max.) |
| Signal Range |
6 m (Max) |
| Environment |
Operating Temp. |
0 ?~50?C |
| Storage Temp. |
-20? ~ 60?C |
| Humidity |
0~80% RH, Non-condensing |
| Physical Properties |
Housing |
Plastic |
| Weight |
0.24 kg |
| Dimension( L x W x H ) |
17.5 x 9.6 x 3.1cm | | | |
|
|
|
|
|
|
 |
 |
